For the ship whose structural scantling information is determined during contractual design process, structural elements such as shell expansion, deck construction, bulkheads together with stiffeners, brackets, webs, floors, girders, etc. are modeled with material specifications in 3D and in accordance with the block division plan. Afterwards following documents and information are prepared for the building of the ship’s hull structure
- Assembly Chart
- Hull Workshop Drawings
- Nesting Drawings
- Detail Engineering
- Numerical Cutting (NC) Codes
- Profile Production Sketches
- Plate and Profile Bending Molds
- Jig Dimensions
- Material Lists
